Kinze 4900 Front Folding Planter Rev. 3/14 - Manual (Page 137)

ITEM PART NO. QTY. DESCRIPTION
1 G2700-06-06 1 Bulkhead Tube Union, 9/16"-18 Male JIC
2 G10328 1 Hex Head Cap Screw, ⅜"-16 x ⅝"
3 GD26754 1 Bracket
4 G306-06 1 Lock Nut, 9/16"-18
5 G6801-06
GR1045 2
-
Elbow W/O-Ring, 90°, 9/16"-18 Male JIC To O-Ring
O-Ring
6 GA18550 1 Hydraulic Tube
7 A18552 1 Barrel (Non-Stock Item)
8 G10640 2 Grease Fitting, ¼"-28
9 G6408-06
GR1045 4
-
Plug W/O-Ring, 9/16"-18 O-Ring
O-Ring
10 G10972 1 Lock Nut, 1¼ "-12
11 *D12148 1 Wear Ring
12 GD14910 1 Piston
13 *D12282 1 T-Seal
14 *D12223 1 O-Ring, No. 124
15 *D12242 1 O-Ring, No. 346
16 *D12243 1 BU Ring
17 *D12255 1 U-Cup Seal
18 GD12522 1 Gland
19 *D12240 1 Wiper, 2"
20 GD12106 1 Ring
21 GA17323 1 Rod
A GA18593 - Hydraulic Cylinder Complete, 4½" x 25¼" (Part Number Stamped on Barrel) (Shown)
B GA18594 - Hydraulic Cylinder Complete, 4½" x 25¼" (Part Number Stamped on Barrel)
C GR2111 - Seal Kit, Includes: (1)Wear Ring, (1)T-Seal, (2)O-Rings, (1)Wiper, (1)BU Ring, (1)
U-Cup Seal
*Item is part of seal kit, item can not be purchased individaully.
Fold Cylinder, 12 Row and 16 Row
Model 4900 M0247-02
