Kinze 4900 Front Folding Planter Rev. 3/14 - Manual (Page 135)

Drawbar Hitch Cylinder
ITEM PART NO. QTY. DESCRIPTION
1 GA14181 1 Rod
2 GD12104 1 Ring
3 *D12200 1 Wiper
4 GD11984 1 Gland
5 *D12253 1 U-Cup
6 *D12203 1 Back-Up Ring
7 *D12202 1 O-Ring, No. 334
8 *D12204 1 O-Ring, No. 218
9 GD11970 1 Piston
10 *D12278 1 T-Seal
11 *D12047 1 Wear Ring
12 GD27237 1 Nylon Lock Nut, 1¼"-12, Grade 8
13 G6400-08-04
GR1465 1
-
Connector W/O-Ring, ¾"-16 Male JIC To 7⁄16"-20 O-Ring
O-Ring
14 G10990 1 Hose Clamp, No. 52
15 A14182 1 Barrel (Non-Stock Item)
16 GA14211 1 Steel Hydaulic Line, 37½"
17 GD12239 1 O-Ring, No. 016
18 GA8882 1 Counter Balance Valve
19 GD20221 1 Block
20 G6408-10
GR1466 1
-
Plug W/O-Ring, ⅞"-14 O-Ring
O-Ring
21 G11355 2 Hex Socket Head Cap Screw, ⅜"-16 x 3 ¾"
22 G6801-08
GR1037 1
-
Elbow W/O-Ring, 90°, ¾"-16 Male JIC To O-Ring
O-Ring
A GA14184 - Cylinder Complete, 3" x 57" (Part Number Stamped On Barrel)
B GR1519 - Seal Kit, Includes: (1)Wiper, (1)U-Cup, (2)O-Rings, (1)BU Ring, (1)T-Seal, (1)Wear
Ring
*Item is part of seal kit, item can not be purchased individaully.
Model 4900 M0247-02
Rev. 2/14 P132
