Kinze 4900 Front Folding Planter Rev. 3/14 - Manual (Page 143)

Slave Cylinder, 16 Row
ITEM PART NO. QTY. DESCRIPTION
1 A17331 1 Barrel (Non-Stock Item)
2 G6408-08
GR1037 2
-
Plug W/O-Ring, ¾"-16 O-Ring
O-Ring
3 G10932 4 Hex Socket Head Cap Screw, 5/16"-18 x 2", Grade 8
4 *D12239 2 O-Ring, No. 016
5 GA16081 1 Check Valve
6 GA17335 1 ⅜ " Hydraulic Steel Tube
7 *D12088 2 Piston Ring, 3½"
8 *D12249 1 Energizer Seal
9 *D12095 1 Piston Seal
10 GD14907 1 Piston
11 *D12226 1 O-Ring, No. 120
12 *D12232 1 BU Ring
13 *D12231 1 O-Ring, No. 338
14 *D12251 1 U-Cup
15 GD12507 1 Gland
16 *D12210 1 Wiper
17 GD12102 1 Ring
18 GA17333 1 Rod
19 G10640 1 Grease Fitting, ¼"-28
20 GD25264 2 Manifold Block
21 G6801-06
GR1045 1
-
Elbow W/O-Ring, 90°, 9/16"-18 Male JIC To O-Ring
O-Ring
22 GD27235 1 Nylon Lock Nut, 1"-14, Grade 8
23 G6408-06
GR1045 3
-
Plug W/O-Ring, 9/16"-18 O-Ring
O-Ring
A GA17330 - Hydraulic Cylinder Complete, 3½" x 9.88" (Part Number Stamped on Barrel)
B GR2113 - Seal Kit, Includes: (2)Piston Rings, (1)Piston Seal, (1)Energizer Seal, (3)O-Rings,
(1)BU Ring, (1)U-Cup, (1)Wiper
C GR1517 - Seal Kit For Counter Balance Valve, Includes: (3) O-Rings, (3) BU Rings
*Item is part of seal kit, item can not be purchased individaully.
Model 4900 M0247-02
Rev. 11/13 P140
