Piston pump with manifolds, 24 row bulkfill – Kinze 4900 Front Folding Planter Rev. 3/14 User Manual
Page 228
ITEM
PART NO.
QTY.
DESCRIPTION
1
GA18327
2
Fertilizer Tube Mount
2
GD26540
2
Fertilizer Tube Mount Bracket
3
GD26542
2
Fertilizer Tube Mount Bracket
4
*GA18332
1
Fertilizer Manifold Assembly, 49"
5
*GA18333
1
Fertilizer Manifold Assembly, 81¾"
6
*GA18334
2
Fertilizer Manifold Assembly, 125¼"
7
*GA18456
1
Fertilizer Manifold Assembly, 81¾"
8
G10110
36
Lock Nut, ¼"-20, Grade B
9
G10674
16
Hose Clamp, No. 24
10
GD28423
1
Clear Tube, 125'
11
GD6291
24
Insulated Clamp, ⅜"
12
GA18344
6
Fertilizer Tube Mount
13
G11458
5
Adapter 1” Flange x 1¼" Hose Barb
14
G11498
9
Gasket, Flange Ribbed 1"
15
GA18590
1
Fertilizer Tee Mount
16
GD11721
2
U-Bolt, 5" x 7" x ½"-13
17
G10102
4
Hex Nut, ½"-13
18
G10228
4
Lock Washer, ½"
19
GA18589
1
Center Fertilizer Manifold Assembly
20
GD26672
2
U-Bolt, 2" Diameter, ¼"-20
21
GD25914
8
U-Bolt, 7" x 3" x ⅝"-11
22
G11467
9
Flange Clamp SS 50 Series
23
GA18875
1
Piston Pump Mount
24
G10001
2
Hex Head Cap Screw, ⅜"-16 x 1"
25
G10014
2
Hex Head Cap Screw, ½"-13 x 1"
26
G11091
2
Serrated Flange Nut, ⅜"-16
27
G10071
6
Serrated Flange Nut, ½"-13
28
GD15532
1
Bronze Bushing, ⅜ x ½"
29
GA11287
1
Double Idler Assembly
30
G11387
9
Flat Washer, ⅜" SAE
31
G10108
1
Lock Nut, ⅜"-16
32
G10306
1
Carriage Bolt, ⅜"-16 x 2"
33
G10552
1
Clevis Pin, ⅜" x 2"
34
G10860
2
Retaining Ring, ⅜"
35
GD5857
1
Spring
36
G10870
1
Clevis Pin, ⅜" x 1"
37
GA12330
1
See "Liquid Fertilizer Piston Pump (Uses 18 Tooth Sprocket)" on page P239
38
---
1
See "Center Ground Drive Assembly" on page P226
39
G10017
4
Hex Head Cap Screw, ½"-13 x 1½"
40
G10308
8
Carriage Bolt, ⅜"-16 x ¾"
41
G3310-82
GR0912
1
-
Chain, No. 40, 82 Pitch Including Connector Link
Connector Link, No. 40
42
G11353
2
Elbow, 1½" NPT, 90˚
43
G11569
2
Adapter, 1" Flange x 1¼" Male NPT
44
GA16837
1
Pressure Relief Valve, 100 PSI
45
G11575
1
1" Flanged Straight Coupling
46
G11583
2
1" Flanged Manifold Tee
47
G4200-15
1
Hose, 1¼" x 65'
48
GD17141
24
Connector, ¼" Male NPT
49
GA18345
4
Hose Support
50
GD26274
16
U-Bolt, 1½" x ¼"-20
51
G10101
8
Hex Nut, ⅜"-16
52
G10104
16
Hex Nut, ⅝"-11
53
G10230
16
Lock Washer,⅝"
54
G10615
2
Reducing Bushing, 1½" Male NPT To 1¼" Female
*
See "Fertilizer Manifold Parts" on page P237
for individual parts.
Piston Pump with Manifolds, 24 Row Bulkfill
TM
M0247-02
Model 4900
P225
Rev. 11/13
