Kinze 4900 Front Folding Planter Rev. 3/14 - Manual (Page 107)

Row Marker Assembly, 12 Row
ITEM PART NO. QTY. DESCRIPTION
19 G10460 5 Cotter Pin, ¼" x 2"
20 GD26783 1 Pin, 1½" O.D. x 10¾"
21 GD15386 2 Pin, 1¼" x 7⅝"
22 G10450 1 Machine Bushing, 1½", 18 Gauge (.0478")
23 GA11592 1 First Stage Marker
24 GA18514 1 See “Row Marker Cylinder, 12 Row” on page P129
25 GA8076
G10641 1 Arm W/Grease Fitting, Second Stage, 72"
Grease Fitting, ⅛" NPT
26 GD2697 1 Pin, ⅞" x 11"
27 GA8075 1 Arm, Third Stage, 35"
28 GA9145 1 Molded Stop, 6¼" Long
29 G10203 2 Washer, ⅜" SAE
30 G10108 3 Lock Nut, ⅜"-16
31 G10047 2 Hex Head Cap Screw, ⅜"-16 x 1¾"
32 GD0453-03 1 Extension Tube, 50"
33 --- - See “Row Marker Spindle/Hub/Blade” on page P111
34 G10045 1 Hex Head Cap Screw, ½"-13 x 4½"
35 G10168 2 Machine Bushing, ½", 7 Gauge (.1793")
36 G10102 4 Hex Nut, ½"-13
37 G10844 1 Carriage Bolt, ½"-13 x 3½"
38 GD2721 1 U-Bolt, 2" x 2" x ½"-13
39 G10463 2 Cotter Pin, ¼" x 1½"
40 GA8072 1 Linkage, 10"
41 G10862 1 Hex Head Cap Screw, ⅝"-11 x 3¼"
42 G10210 2 Washer, ⅜" USS
43 G10049 1 Hex Head Cap Screw, ⅜"-16 x 2½"
44 GD2971-11 1 Sleeve, 1⅞" Long
45 GD8218 1 Yoke
46 G10560 2 Clevis Pin, ½" x 1¾"
47 G10451 2 Cotter Pin, ⅛" x 1"
48 G10503 1 Hex Jam Nut, ⅝"-11, Grade 2
49 GD11115 1 Plain Yoke
50 G10159 2 Washer, 1⅞"
51 GD21143 1 Marker Pin, 1¼" x 9½"
52 G10640 2 Grease Fitting, ¼"-28
53 G11400 2 Retaining Ring, 1¼"
54 GD21142 1 Marker Pin, 1¼" x 13/16"
55 G10942 1 Hex Head Cap Screw, ⅝"-11 x 2½", Full Thread
56 G10104 1 Hex Nut, ⅝"-11
57 G6400-08-04
GR1465 1
-
Connector W/O-Ring, ¾"-16 Male JIC To 7/16"-20 O-Ring
O-Ring
58 G6801-08
GR1037 1
-
Elbow W/O-Ring, 90°, ¾"-16 Male JIC To O-Ring
O-Ring
59 GA15032-62 2 Hose Assembly, ⅜" x 62" (08F-08F) (Abrasion Resistant)
60 GA11915
G3302-07
GD10674-02 1
1
1 Marker Chain Assembly
Coil Chain, No. 9/0, 28 Links
Chain Cover, 56"
61 GA8170
G10536 1 Safety Lockup W/Detent Pins, 19⅜"
Detent Pin, ½" x 2½"
62 G6502-08 - Swivel Elbow, 45°, ¾"-16 Male JIC To Female
63 G10218 1 Washer, ¾" USS
64 --- - ---
65 GD26962 1 Lockup Storage Plate
66 GD11489 1 U-Bolt, 3" x 6" x ⅝"-11
67 G10205 2 Washer, ⅝" SAE
Model 4900 M0247-02
Rev. 11/13 P104
TM
