Fertilizer Shut Off
ITEM PART NO. QTY. DESCRIPTION
1 GR2162 1 O-Ring
2 *R2163 1 O-Ring
3 GR2165 1 Interface Cap
4 GR2167 1 Spring
5 GR2168 1 Plunger
6 *R2169 1 O-Ring
7 GR2170 1 Tube
8 GR2171 1 Nylon Black Locking Ring
9 GR2172 1 Coil
10 *R2173 1 Washer
11 *R2174 1 Black Nylon Nut
12 GR2177 1 Mini-Din Cable
A GA14808 - Fertilizer Valve (Items 1-12)
B GR2175 Parts Kit (Items 2, 6, 10-11)
*Item is part of seal kit, item can not be purchased individaully.
(A14808)
1
2
3
4
5
6
7
8
9
10
11
12
Model 4900 M0247-02
Rev. 11/13 P248
