Row marker assembly, 16 row – Kinze 4900 Front Folding Planter Rev. 3/14 User Manual
Page 110
Row Marker Assembly, 16 Row
ITEM
PART NO.
QTY.
DESCRIPTION
27
GD25860
1
Marker Pin, 1¼" x 8⅞"
28
G11400
2
Retaining Ring, 1¼"
29
GA18533
1
L.H. Marker Pivot
30
G10006
5
Hex Head Cap Screw, ⅝"-11 x 2¼"
31
G10104
1
Hex Nut, ⅝"-11
32
GA18485
2
Shear Strap
33
GA15032-51
2
Hose Assembly, ⅜" x 51" (08F-08F) (Abrasion Resistant)
34
G10159
2
Washer, 1⅞"
35
G6502-08
2
Swivel Elbow, 45°, ¾"-16 Male JIC To Female
36
GD26783
1
Pin, 1½" O.D. x 10¾"
37
GD18828
1
Washer
38
G10014
1
Hex Head Cap Screw, ½"-13 x 1"
39
G10450
1
Machine Bushing, 1½", 18 Gauge (.0478")
40
G10640
1
Grease Fitting, ¼"-28
41
GD25953
1
Shear Strap Pin
42
GA18884
G10874
1
-
Cylinder Lock-up Assembly
Detent Pin, ½" x 3½" Grip
43
G11553
4
Hex Head Cap Screw, 5/16"-18 x 3"
44
G304-C-8
2
Cap Nut, ¾"-16
45
G6400-08
GR1037
2
-
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
46
G11391
10
Flat Washer, ⅝" SAE
47
G10038
1
Hex Head Cap Screw, ½"-13 x 3"
48
G10942
1
Hex Head Cap Screw, ⅝"-11 x 2½", Full Thread
49
GD19205
2
Chain Spacer
50
GD19206
1
Chain Sleeve
51
G10544
2
Cotter Pin, 5/32" x 1"
52
G3302-15
1
Marker Chain, 43 Links
53
G10107
5
Lock Nut, ⅝"-11
54
GD10674-07
1
Chain Cover
55
G10585
1
Hex Head Cap Screw, ½"-13 x 3¼"
56
GD26789
1
Stop Shim
57
GD26790
1
Stop Pad
58
G11180
3
Hex Flat Head Counter Sunk Cap Screw, ¼"-20 x 1"
59
G10110
3
Lock Nut, ¼"-20, Grade B
60
G11385
3
Flat Washer, ¼" SAE
61
G10106
8
Hex Nut, 5/16"-18
62
G10218
1
Washer, ¾" USS
TM
M0247-02
Model 4900
P107
Rev. 11/13
