Kinze 4900 Front Folding Planter Rev. 3/14 - Manual (Page 113)

Row Marker Assembly, 24 Row
ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
23 G10228 10 Lock Washer, ½"
24 G10102 10 Hex Nut, ½"-13
25 G10844 1 Carriage Bolt, ½"-13 x 3½"
26 G10045 1 Hex Head Cap Screw, ½"-13 x 4½"
27 G10111 7 Lock Nut, ½"-13
28 G10581 1 Hex Head Cap Screw, ½"-13 x 2¼"
29 G10033 1 Hex Head Cap Screw, ½"-13 x 3½"
30 GD0704 1 Pin, 1¼" x 14"
31 GD25862 1 Wear Stop
32 G11534 3 Hex Flat Head Counter Sunk, ½"-13 x 1¾"
33 G10159 2 Washer, 1⅞"
34 G10460 4 Cotter Pin, ¼" x 2"
35 G10110 2 Lock Nut, ¼"-20, Grade B
36 G304-C-8 2 Cap Nut, ¾"-16
37 G6502-08 2 Swivel Elbow, 45°, ¾"-16 Male JIC To Female
38 G6400-08
GR1037 2
-
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
39 GA18861 1 See “Row Marker Cylinder, 16 Row and 24 Row” on page P130
40 GD8218 1 Yoke
41 GD11115 1 Plain Yoke
42 G10585 2 Hex Head Cap Screw, ½"-13 x 3¼"
43 G10503 1 Hex Jam Nut, 5⅝"-11, Grade 2
44 GD28630 1 Wire Rope, 153¾"
45 G11385 2 Flat Washer, ¼" SAE
46 G11570 2 Hex Flat Head Cap Screw, ¼"-20 x 1½"
47 GA15032-51 2 Hose Assembly, ⅜" x 51" (08F-08F) (Abrasion Resistant)
48 GD26954 2 Shim Stop
49 GD26955 1 Stop Pad
50 GA18734 1 Marker Stand
51 GD25914 2 U-Bolt, 7" x 3" x ⅝"-11
52 G10107 4 Lock Nut, ⅝"-11
53 G11391 4 Flat Washer, ⅝" SAE
54 GD2597 1 Retainer
55 G10725 1 Slotted Hex Nut, ⅝"-18
56 G11391 1 Flat Washer, ⅝" SAE
57 GA15162
GD21540
GA0257
GA0245
GA0167 1
-
-
-
-
4-Bolt Hub Assembly W/O Spindle
Grease Seal
Bearing
Bearing
Hub W/Cups, 4 Bolt
58 G10544 1 Cotter Pin, 5/32" x 1"
59 GD0840 1 Dust Cap
60 GD3248 4 Lug Bolt, ½"-20 x 1¼"
61 GD7817-04 2 Spacer, 11/16" I.D. x ½" Long
62 GD19206 1 Chain Sleeve
Model 4900 M0247-02
Rev. 2/14 P110
