Kinze 4900 Front Folding Planter Rev. 3/14 - Manual (Page 15)

ITEM PART NO. QTY.
(Per Row)
DESCRIPTION
1 GD10473 2 Bearing Housing
2 GA2014 2 Bearing
3 G10801
G10102 2
2 Carriage Bolt, ½"-13 x 2¼"
Hex Nut, ½"-13
4 GA2054 1 Spring
5 GB0239 2 Eccentric Bushing
6 G10102 1 Hex Nut, ½"-13
7 G10015 1 Adjusting Bolt, ½"-13 x 5"
8 GA6619 1 Mounting Arm
9 G10463 2 Cotter Pin, ¼" x 1 ½"
10 G10171
G10232
G10106 4
4
4 Hex Head Cap Screw, 5∕16"-18 x 1¼"
Lock Washer, 5∕16"
Hex Nut, 5∕16"-18
11 GA6620 2 Bracket
12 GA6618 2 Mount
13 G10303
G11386
G10232
G10106 2
2
2
2 Carriage Bolt, 5∕16"-18 x 1"
Flat Washer, 5∕16" SAE
Lock Washer, 5∕16"
Hex Nut, 5∕16"-18
14 G10107 3 Lock Nut, ⅝"-11
15 GD1109 2 Bushing, 41∕64" I.D. x ⅞" O.D. x ¼" Long
16 GD9290 2 Disc Blade, 8"
17 G10427 12 Rivet, ¼" x ½"
18 G10152 1 Hex Head Cap Screw, ⅝"-11 x 9"
19 GD3180-12 2 Sleeve, ⅝" I.D. x ⅞" O.D. x 2⅞" Long
20 G10006 2 Hex Head Cap Screw, ⅝"-11 x 2¼"
21 GD11845 2 Dust Cap
22 GA18773 - Single Press Wheel Complete W/Bearing
A GA6801 - Covering Disc Blade Complete W/Bearing (Items 1-2 and 16-17)
Covering Discs/Single Press Wheel
Model 4900 M0247-02
Rev. 11/13 P12
TM
