Slave Cylinder, 12 Row
ITEM PART NO. QTY. DESCRIPTION
1 GA17671 1 Barrel (Non-Stock Item)
2 G6408-08
GR1037 2
-
Plug W/O-Ring, ¾"-16 O-Ring
O-Ring
3 G10932 4 Hex Socket Head Cap Screw, 5⁄16"-18 x 2", Grade 8
4 G6801-06
GR1045 1
-
Elbow W/O-Ring, 90°, 9⁄16"-18 Male JIC To O-Ring
O-Ring
5 GD12239 2 O-Ring, No. 016
6 GA16081 1 Check Valve
7 GA17673 1 ⅜ " Hydraulic Steel Tube
8 GD27235 1 Nylon Lock Nut, 1"-14, Grade 8
9 *D12144 2 Piston Ring
10 *D12145 1 Piston Seal
11 GD12273 1 Seal
12 GD14901 1 Piston
13 *D12226 1 O-Ring, No. 120
14 *D12270 1 O-Ring, No. 340
15 *D12271 1 BU Ring
16 *D12269 1 U-Cup Seal
17 *D14902 1 Gland
18 *D12268 1 Wiper
19 GD12102 1 Ring, 1¼"
20 GA17672 1 Rod
21 G10640 1 Grease Fitting, ¼"-28
22 GD25264 2 Manifold Block
23 G6408-06
GR1045 3
-
Plug W/O-Ring, 9/16"-18 O-Ring
O-Ring
A GA17670 - Hydraulic Cylinder Complete, 3¾" x 9⅞" (Part Number Stamped on Barrel)
B GR2141 - Seal Kit, Includes: (4)O-Rings, (1)Wiper, (1)U-Cup, (1)BU Ring, (1)Piston Ring, (1)
Piston Seal, (1)Energizer Seal
*Item is part of seal kit, item can not be purchased individaully.
Model 4900 M0247-02
Rev. 11/13 P138
