Kinze 4900 Front Folding Planter Rev. 3/14 - Manual (Page 27)

Row Unit Mounted Double Residue Wheels
ITEM PART NO. QTY.
(Per Row)
DESCRIPTION
1 GD10519 1 Spring
2 GD9720 2 Spacer, ½” x 23/16" Long
3 GB0218 4 Bushing, 21/32" I.D. x ⅞" O.D. x 19/32" Long
4 G11391 4 Flat Washer, ⅝" SAE
5 G10005 4 Hex Head Cap Screw, ⅝"-11 x 1¾"
6 G10033 2 Hex Head Cap Screw, ½"-13 x 3½"
7 G10111 4 Lock Nut, ½"-13
8 G10636 4 Carriage Bolt, ½"-13 x 1½"
9 GA8760
G10765 2
-
Weed Guard W/Spring Pin
Spring Pin, ¼" x 1"
10 G10213 4 Machine Bushing, ⅝" (.030" Thick)
11 GB0387 2 Wheel, 12 Tine, ⅜" x 12"
12 GA5654 2 Hub W/Bearings (Includes Item 13)
13 GA2014 2 Bearing
14 GD9724 2 Backing Plate
15 G10133 12 Hex Head Cap Screw, 5/16"-18 x 1½"
16 G10109 12 Lock Nut, 5/16"-18, Grade 8
17 G11124 2 Hex Serrated Flange Cap Screw, ⅜"-16 x 1"
18 GD5857 2 Spring
19 G10010 2 Hex Head Cap Screw, ⅝"-11 x 3"
20 G10503 2 Hex Jam Nut, ⅝"-11, Grade 2
21 GD1132 2 Dust Cap
22 G10102 2 Hex Nut, ½"-13
23 G10228 2 Lock Washer, ½"
24 G11389 1 Flat Washer, ½" Plated SAE
25 G10974 1 Lock Nut W/Nylon Insert, ½"-13
26 G11109 1 Hex Head Cap Screw, ½"-13 x 7½"
27 G10620 2 Serrated Flange Nut, 5/16"-18
28 G10303 2 Carriage Bolt, 5/16"-18 x 1"
29 GA18099 1 Mount
30 GA18100 1 Upper Link
31 GA18101 1 Lower Link
32 GA18102 1 Cam
33 GA18103 1 Wheel Mount
34 GD26262 1 CAM Mount Plate
35 GA18098 1 Cam Mount Block
A GA12235 - L.H. Residue Wheel (Items 11-12 and 14-16)
B GA12236 - R.H. Residue Wheel (Items 11-12 and 14-16)
Model 4900 M0247-02
Rev. 11/13 P24
