Kinze 4900 Front Folding Planter Rev. 3/14 - Manual (Page 151)

ITEM PART NO. QTY. DESCRIPTION
1 A17315 1 Barrel (Non-Stock)
2 GA16081 1 Check Valve
3 G6408-08
GR1037 4
-
Plug W/O-Ring, ¾"-16 O-Ring
O-Ring
4 G6801-06
GR1045 1 Elbow W/O-Ring, 90°, 9/16"-18 Male JIC To O-Ring
O-Ring
5 GD23226 1 Manifold Block
6 G10932 2 Hex Socket Head Cap Screw, 5/16"-18 x 2", Grade 8
7 GA17318 1 ⅜ " Hydraulic Steel Tube
8 G6400-08
GR1037 2 Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
9 GA17319 1 ½ " Hydraulic Steel Tube
10 GA8882 1 Counter Balance Valve
11 *D12239 1 O-Ring, No. 016
12 GD27235 1 Nylon Lock Nut, 1"-14, Grade 8
13 *D12135 2 Piston Ring
14 *D12072 1 Cast Iron Ring
15 *D12224 1 Energizer Seal
16 GD14897 1 Piston
17 *D12226 1 O-Ring, No. 120
18 *D12221 1 O-Ring, No. 342
19 *D12222 1 BU Ring
20 *D12252 1 U-Cup
21 GD11988 1 Gland
22 *D12206 1 Wiper, 1½"
23 GD12103 1 Ring
24 GA17317 1 Rod
25 G10640 1 Grease Fitting, ¼"-28
A GA17314 - Hydraulic Cylinder Complete, 4" x 12" (Part Number Stamped on Barrel)
B GR2110 - Seal Kit, Includes: (2)Piston Ring, (1)Energizer Seal, (1)Piston Seal, (3) Piston Seal,
(1)Wiper, (1)U-Cup, (1)BU Ring
*Item is part of seal kit, item can not be purchased individaully.
Master Cylinder, 16 Row
Model 4900 M0247-02
Rev. 2/14 P148
