ITEM PART NO. QTY. DESCRIPTION
1 --- - See “Hitch and H-Frame Assembly, 24 Row” on page P77
2 GA18141
GA18142 1
1 60' L.H. Wing (Shown)
60' R.H. Wing
3 G10055 2 Hex Head Cap Screw, ⅝"-11 x 1¼"
4 GA16756 1 R.H. Draft Link
5 GA16757 1 L.H. Draft Link
6 GA19331 2 Hammer Strap Pin, 10"
7 GA19332 2 Hammer Strap Pin, 5¾"
8 GA16884
G10039
G11389
G10111 2
2
2
2 Hammer Strap 9⅛"
Hex Head Cap Screw, ½"-13 x 1¾"
Flat Washer, ½" Plated SAE
Lock Nut, ½"-13
9 GA16885 2 Hammer Strap Pin, 3⅝"
10 GA17347 2 See “Wing Down Pressure Cylinder” on page P153
11 G11391 2 Flat Washer, ⅝" SAE
12 G10039
G11389
G10111 2
2
2 Hex Head Cap Screw, ½"-13 x 1¾"
Flat Washer, ½" Plated SAE
Lock Nut, ½"-13
13 G10027
GD28426 2
2 Hex Head Cap Screw, ¾"-10 x 2½"
Washer
14 GD28428 2 Wing Pivot Pin
15 GD24425 2 Capture Plate
16 GA18591 1 See “Fold Cylinder, 24 Row” on page P135
17 GA18592 1 See “Fold Cylinder, 24 Row” on page P135
18 GD27088-01
G11593 4
8 Pin, 1.225" x 9¼"
External Spiral Retaining Ring, 1¼"
Draft Links and Wings, 24 Row
Model 4900 M0247-02
Rev. 2/14 P74
