H-Frame Sub-Assembly, 12 and 16 Row
ITEM PART NO. QTY. DESCRIPTION
1 GA19185
GA19186 1
-
H-Frame, 12 Row
H-Frame, 16 Row
2 GA13204 1 Hall Effect Sensor
3 GA19335 1 Sensor Bracket
4 GA19187 8 Master Cylinder Pin
5 GA17368
GA18899 4
-
Center Wheel Module, 12 Row
Center Wheel Module, 16 Row
6 GA17372
GA18911 4
-
Hammer Strap Pin, 12 Row
Hammer Strap Pin, 16 Row
7 GA17612
GA17314 4
-
See “Master Cylinder, 12 Row” on page P145
See “Master Cylinder, 16 Row” on page P147
8 GA17761
GA17765 4
-
See “H-Frame Tire and Hub Assembly, 12 Row” on page P113
See “H-Frame Wheel and Hub Assembly, 16 Row and 24 Row Wing Wheel and Hub
Assembly, 24 Row” on page P114
9 GA4736
GA18901 4
-
See “H-Frame Tire and Hub Assembly, 12 Row” on page P113
See “H-Frame Wheel and Hub Assembly, 16 Row and 24 Row Wing Wheel and Hub
Assembly, 24 Row” on page P114
10 GD21759-12
GD21758-08 4
-
Pin, 1¼" x 4.95", 12 Row
Pin, 1½" x 5.019", 16 Row
11 G10020
G10227
G10103 2
2
2 Hex Head Cap Screw, ¼"-20 x ⅝"
Lock Washer, ¼"
Hex Nut, ¼"-20
12 G10007 8 Hex Head Cap Screw, ⅝"-11 x 1½"
13 G10016 8 Hex Head Cap Screw, ½"-13 x 2"
14 G10111 8 Lock Nut, ½"-13
15 G10230 8 Lock Washer, ⅝"
16 G10330 8 Lock Washer, ⅞"
17 G11593
G11621 8
8 External Spiral Retaining Ring, 1¼", 12 Row
External Spiral Retaining Ring, 1½", 16 Row
18 G10448 8 Hex Head Cap Screw, ⅞"-9 x 2½", Grade 8
19 GD18646 1 Sensor Bracket Cover
20 G11389 8 Flat Washer, ½" Plated SAE
21 GD18676 4 Lug Bolt, ⅝"-18 x 2¾"
22 GD19252 1 Cable Guard
23 GD18643 1 Jump Start Wheel
24 G11254 4 Serrated Flange Nut, ⅝"-18
25 G10857 2 Hex Head Cap Screw, ¼"-20 x 1¼"
26 G10621 2 Serrated Flange Nut, ¼"-20
27 GA19393 1 Jump Start Cable
