Kinze 4900 Front Folding Planter Rev. 3/14 User Manual
Page 81
ITEM
PART NO.
QTY.
DESCRIPTION
1
GA16752
1
R.H. Stub Wing
2
GA16753
1
L.H. Stub Wing
3
---
1
4
GA16893
2
Stub Wing Latch
5
---
1
See “H-Frame Sub-Assembly, 24 Row” on page P83
6
GD24786-03
2
Shim, 10 Gauge (.1345") (As Required)
7
GD24786-04
2
Shim, 12 Gauge (.1046") (As Required)
8
GD24420
2
Main Pivot Pin
9
GD24786-01
8
Shim, ¼"
10
GD25499
2
U-Bolt, 8" x 16" x ¾"-10
11
GD27432
1
Hydraulic Block Mount Plate, 24 Row
12
G10009
4
Hex Head Cap Screw, ⅝"-11 x 2½"
13
G10058
2
Hex Head Cap Screw, ¾"-10 x 5½"
14
G10107
4
Lock Nut, ⅝"-11
15
G10112
6
Lock Nut, ¾"-10
16
G11217
10
Hex Head Cap Screw, ⅞"-9 x 3½"
17
G10418
12
Lock Nut, ⅞"-9
18
G11027
2
Hex Head Cap Screw, 7/8"-9 x 4"
19
G11391
4
Flat Washer, ⅝" SAE
20
G11392
4
Flat Washer, ¾" SAE
21
G10415
4
Carriage Bolt, ⅝"-11 x 2¼"
22
GA19303
1
L.H. Hose Guide, 24 Row
23
GA19304
1
R.H. Hose Guide, 24 Row
24
G11393
2
Flat Washer, ⅞"
25
GD24786-02
2
Shim, 7 Gauge (.1793") (As Required)
Hitch and H-Frame Assembly, 24 Row
Model 4900
M0247-02
Rev. 11/13
