ITEM PART NO. QTY. DESCRIPTION
1 GA18785 1 200 Gallon Tank Mount
2 GA17901
GA16428
GA16157
GR2056
GR0508
GR1941
GR2144 1
1
1
1
3
1
1 Tank W/Lid and Fittings, 200 Gallon
7" Lid Assembly
Vacuum Breaker
7" Lid W/2" NPT
1¼" Polypropylene Fitting Assembly (Nut, Bushing And O-Ring)
Seal
½
" Bulkhead Fitting
3 GA2660 1 Shutoff Valve, 2" NPT
4 GA18180 1 3-Way Flanged Ball Valve, 2"
5 GA18181 1 1" Manifold T Strainer W/30 Mesh Screen
6 GA18182 1 1" Manifold T Strainer W/80 Mesh Screen
7 GA18796 1 Hose Guide
8 GD3623 1 Adapter, 2" Male NPT To Cam Lock
9 GD3951 1 Dust Cap, 2" Cam Lock
10 GD11123 4 Anchor Strap
11 GD11124 2 Strap, 84"
12 GD20111 1 Hose Bracket
13 GD25235 2 U-Bolt, 8" x 12" x ¾"-10
14 GD26338 1 2" Flange x 1¼" Male
15 G4304-02 1 Clear Plastic Tube, ½" x 33"
16 G10673 2 Hose Clamp, No. 8
17 GD26982 1 Fertilizer Tube Support Plate
18 GD26472 2 2" x 2", 90° Full Port Flange
19 GD26535 2 U-Bolt, 2½" x ⅜"-16
20 G4201-03 1 Hose, 2" x 18'
21 G4602-03 1 Black Helix Hose, 1¼" x 100'
22 G10001 4 Hex Head Cap Screw, ⅜"-16 x 1"
23 G10037 6 Hex Head Cap Screw, ½"-13 X 1¼"
24 G10096 1 Pipe Plug, ¾" NPT
25 G10108 6 Lock Nut, ⅜"-16
26 G10112 4 Lock Nut, ¾"-10
27 G10485 8 Hex Head Cap Screw, ⅜"-16 x 5"
28 G10626 1 Adapter, 1¼" NPT To Barb
29 G10628 1 Adapter, 2" NPT To Barb
30 G10674 2 Hose Clamp, No. 24
31 G10676 2 Hose Clamp, No. 36, Stainless Steel
32 G10901 8 Lock Nut W/Nylon Insert, ⅜"-16
33 G11387 2 Flat Washer, ⅜" SAE
34 G11389 4 Flat Washer, ½" Plated SAE
35 G11455 1 Reducer, 2" Flange x 1” Flange
36 G11457 2 Elbow, 2" Flange x 2" Hose Barb, 90°
37 GA8983 - Check Valve, Low Rate
38 G11467 2 Flange Clamp SS 50 Series
39 G11468 6 Flange Clamp SS 75 Series
40 G11498 2 Gasket, Flange Ribbed 1"
41 G11499 6 Gasket, Flange Ribbed 2"
42 G10297 1 Hex Pipe Plug, ½"
43 GD18329 1 U-Bolt, 3" x 5/16"-18
44 GD26816 1 2" Flange x 2" Male Thread
Liquid Fertilizer Tank Hoses and Fittings,
12 Row with Bulkfill
(Continued on the following page.)
Model 4900 M0247-02
Rev. 11/13 P206
