3.11.3.2 Source Setup

Source setup parameters are identical to the sensor setup parameters, with one
exception.

Voltage Scale: Sets the maximum output voltage for the source power supply
input. Voltages from –10 V to +10 V are possible. Your power supply manual will
state the required input voltage, typically 10 V, 5 V, -10 V, or –5 V.

CAUTION

If changes are made in the Logic Menu, be sure to exit to
the System Menu or Main Screen before powering down.
Your changes will not be saved otherwise.
