SQC-310 Operating Manual
Figure 1-9 Layer Select Menu
A process consists of one or more layers. Each layer can have a different film, or
even multiple films (Co-deposition). For this example, we will stop with only a
single layer. Layers are displayed as "Layer x.y", where x is the layer number and
y is the source number assigned to the layer.
Figure 1-10 Edit Layer Menu
Table 1-7 Edit Layer
Edit
Layer With Layer 1.1 selected, press Edit to display the Layer Edit menu
for Layer 1.1.
