SQC-310 Operating Manual
Selecting Edit on the Process Select Menu shows the sequence of layers that will
be deposited in the selected process.
Figure 3-4 Layer Select Menu
Table 3-5 Process Select Menu SoftKeys
To
Main Returns to the Main Screen, Menu 3.
Edit... Edit displays the Layer Select Menu for the current process.
Edit
Name... Displays the character entry screen to edit the selected process
name.
Delete Deletes the highlighted process and all of its layers. A prompt will
follow if delete is selected to safeguard against accidental process
deletion.
Copy/Paste Copies the highlighted process and all of its layers. Scroll to an
Empty process and press Paste to paste the copied process.
Table 3-6 Layer Select Menu SoftKeys
Main
Screen Returns to the Main Screen Menu 3.
Prev
Menu Returns to the Process Select Menu.
