3 - 24

IP

N 07

4-

55

0-

P1

B

SQC-310 Operating Manual

Relay Number: The physical output assigned to this logical relay function. This
allows for re-assignment of relays without physically re-wiring any relays or
connectors. Connector pins for these assignments are shown in

Table 3-11

.

CAUTION

If changes are made in the Input or Relay Menu, be sure
to exit to the System Menu or Main Screen before
powering down. Your changes will not be saved
otherwise.

Table 3-11 Relay & Input Connector Pin Assignments

Relay

Number

Connector

Pins

Input

Number

Connector

Pin

Relay 1

14,15

Input 1

16

Relay 2

1,2

Input 2

17

Relay 3

3,4

Input 3

18

Relay 4

5,6

Input 4

19

Relay 5

7,8

Input 5

20

Relay 6

9,10

Input 6

21

Relay 7

11,12

Input 7

22

Relay 8

13,25

Input 8

23

Ground

24
