SQC-310 Operating Manual
I/O Connector Wiring
C.2 Interfacing to a INFICON CI-100 Indexer
C.2.1 BCD I/O
BCD wiring is suggested over Binary I/O wiring because it uses fewer relays. The
wiring below interfaces the SQC-310 I/O connector to the CI-100 BCD I/O
connector for controlling an 8 pocket source.
SQC-310
CI-100 BCD I/O
Pin 14------------->-------------- Pin 1 OutX Pocket Bit1
Pin 1 -------------->-------------- Pin 2 OutX Pocket Bit2
Pin 3 -------------->-------------- Pin 7 OutX Pocket Bit3
Pin 16 ------------<-------------- Pin 5 OutX Pocket Ready
Pin 15,2,4------------------------ Pin 6 Common
Short Pin 3 to Pin 9 Interlock
Short Pin 4 to Pin 8 Pocket Ready A
On the CI-100 rear panel: set Select On/Off Switch #5 UP and #7 DOWN.
On the SQC-310 System Menu, Sensors & Sources set up the source with:

Number of Positions: 8
 Control Type: BCD
 Feedback Type: In Position
 Indexer Delay: 5 seconds
MDC 991270 and Sycon SRT-400 Indexer compatibility: The CI-100 pins 1, 2, 3,
and 7 are identical to the MDC and Sycon indexers. For a compatible pocket ready
signal (pin 5), jumper pin 4 to pin 6. Set Select Switch #7 UP.
Table C-1 I/O Connector Wiring
Relay Pins Input Pins
Relay 1 14,15 Input 1 16
Relay 2 1,2 Input 2 17
Relay 3 3,4 Input 3 18
Relay 4 5,6 Input 4 19
Relay 5 7,8 Input 5 20
Relay 6 9,10 Input 6 21
Relay 7 11,12 Input 7 22
Relay 8 13,25 Input 8 23
Ground 24
