Chatsworth Products Remote Infrastructure Management (RIM-1000) - Manual (Page 96)

Remote Infrastructure Management System - Version 1.0 / July 2014
96 www.chatsworth.com
3.4.23 Modbus/SNMP/BACnet/Telnet Master
This section provides configuration information for basic Master unit functionality. If you’d like to configure more advanced features,
refer to Chapter 4, “Advanced Communications - Modbus, BACnet, and Telnet” on page 129.
These pages allow users to configure Modbus, SNMP, BACnet, and Telnet features. While most functionality is detailed here, some ad-
vanced communications and logging options are described in greater detail in Chapter 4, “Advanced Communications - Modbus, BACnet,
and Telnet” on page 129.
If you wish to configure the unit as a BACnet Master, BACnet communications must first be configured. Refer to section “BACnet” on page
94 for more information.
If you’d like to use the RIM-1000’s Telnet capabilities, refer to “Telnet/COM1 Configuration” on page 149.
Figure 3.38 Modbus/SNMP/BACnet/Telnet Master Configuration
Figure 3.38 Modbus/SNMP/BACnet/Telnet Master Configuration
Option Description
Modbus/TCP Slave
Enable
Use this option to enable the RIM-1000 as a Modbus Slave over Ethernet TCP/IP.
Modbus/TCP Slave
Unit Identifier
Set the RIM-1000 Modbus/TCP Slave address (1-254). 0 = disabled.
