Remote Infrastructure Management System - Version 1.0 / July 2014
Chatsworth Products, Inc. (CPI) • 800-834-4969 51
Table 3.3 RIM-1000 Main Board Configuration Options
Note: Press the Submit Changes button when done to save all changes.
Option Description
BACnet Instance
The BACnet object identifier. It is a numerical code used to identify
the input. This code must be unique within the BACnet device
BACnet Units
A numerical code used to assign engineering units to this BACnet
Instance. Refer to the BACnet standard for further information.
The next five rows contain information that pertains to graphical mapping.
Map Box Size
If you’re creating an interactive map for your facility, this field is
helpful. It allows you to customize the size of the mapped object for
this input point.
By default, the height of the object, as it appears on the map, is
approximately 20 pixels, and the width automatically adjusts to the
length of the text. This setting allows users to expand the size of the
object to fill a defined area.
Text Direction
Used for graphical mapping - decide if you’d like the text on the
map for this object (temperature reading, humidity reading, sensor
value, etc.) to be horizontal or vertical.
Map Coordinate
Fine tune the location of the object on the map. Refer to “Facility
Mapping” on page 129 for further information.
Graphical Mapping Designate the device’s location on the RIM-1000 graphical map.
Test Map View the mapped location of the point you’re currently configuring.
Digital Input Color -
Active and Inactive
Inputs configured for Digital Status do not trigger notification.
Instead, use this option to set the display color for Digital Status
points on the Main Menu when the input in its inactive state, and
also when it is turned on to its active state.
The options include red, gold, magenta, gray, and green.
Typically, points are configured to be green in their inactive state
and then to turn red on alarm.
Group Assignment
Inputs can be organized by groups on the RIM-1000’s main page. Users
can separate inputs into up to 8 groups. If you’d like this input to
appear as part of a group, designate that here.
Email Url Link
Email links can be included in RIM-1000 notification - popular links
include links to emergency recovery plans and links to user guides.
Links are configured through the Configuration>Email URL Links
page.
If you’d like, you can include one URL link in each email message.
Use the “Email URL Links” configuration page to set up the URL
links, and then enter the number associate with the link you’d like to
send here.
