A P P E N D I X
A
RIM-1000 EXPANSION CARDS
A.1.
Expansion Card Descriptions
Expansion cards can be added to a base RIM-1000 unit to increase its functionality. A 1U RIM-1000 has room for one expansion card.
A 2U RIM-1000 has room for three expansion cards. Currently, Expansion Card A and Expansion Card C are available from CPI.
Expansion cards A and C are populated as follows:
Table A.1 Expansion Card Descriptions
Card
Features
Product Part Number
A
12 Analog Inputs (AI) Individually configurable through
jumpers, as 4-20mA, 0-5VDC, or 0-10VDC
8 Relay Outputs (RO)
60103-001
C
24 Digital Inputs (DI)
Select the 24VDC or 48VDC option
60103-002 (24 VDC)
60103-003 (48 VDC)
