3.4.13 Keypad/DTMF Access Users
If your RIM-1000 has a keypad attached to it, use the Keypad/DTMF Access Users link to configure a maximum of 20 access codes
and user names.
Figure 3.28 Keypad/DTMF Access Users Configuration
Table 3.17 Keypad/DTMF Access Users Configuration Options
Option Description
Id Code Up to six digits long, users enter this code into the keypad to gain access.
User Name
Enter a user name that will be linked to the access code. The user name can be
up to 20 characters long.
Type
Permanent - The code is active for an unlimited amount of time.
Temporary - This code is only active during the parameters specified in the
Temporary Time Settings.
Temporary Time
Setting
Access codes designated as temporary are only active during this specific window
of time, which is established near the bottom of the Keypad Configuration Page.
Configure the appropriate span of time and click the Set Temporary Time button to
activate the settings. The amount of time remaining in the temporary window
displays on the countdown clock.
Once the time frame has expired, the temporary users will not be allowed access.
However, their information will remain in the Keypad/DTMF field until it is manu-
ally removed. While temporary users will not be allowed access to a facility after
their allotted time slot, no alarm notification will be transmitted if they try to
re-enter the facility through the keypad. Their information must be manually
removed from the system in order to activate the alarm notification.
