Chatsworth Products Remote Infrastructure Management (RIM-1000) - Manual (Page 95)

Remote Infrastructure Management System - Version 1.0 / July 2014
Chatsworth Products, Inc. (CPI) • 800-834-4969 95
Table 3.25 BACnet Configuration Options
Option Description
BACnet UDP Port
This is the port to which the RIM-1000 will respond to BACnet requests. Enter
a 0 to specify port 47808 (0xBAC0) as the UDP port. If another port is specified
by your device, enter that value here.
Default: 0
Register as Foreign
Device IP This is the IP address of the master device with which you’re trying to
communicate. Requires a BBMD for foreign device discovery.
Registration Timeto-Live Time, in seconds, for foreign device discovery.
BACnet BBMD-BDT
BACnet BBMD information will usually not need to be edited from the RIM-1000. If the RIM-1000 is acting as a
BACnet router, these fields will automatically be populated by the BACnet network controller.
RIM-1000 IP Address
An uneditable field, this is the IP address of the RIM-1000 you’re currently
logged into.
#1 - #4 IP Address
These fields are usually written TO by other devices, and not configured
through these screens. If there is data in these fields, it means another
device has communicated with this RIM-1000 via BACnet BBMD.
Port
Mask
BACnet Packet Log
