Chatsworth Products Remote Infrastructure Management (RIM-1000) - Manual (Page 5)

Remote Infrastructure Management System - Version 1.0 / July 2014
Chatsworth Products, Inc. (CPI) • 800-834-4969 5
Contents
RIM-1000 User Guide
1 System Overview 15
Product Description 15
1U and 2U RIM-1000 Devices 15
Front Panel Indicators and Controls 16
Terminal Block Designations 17
Rear Panel Indicators 19
SW1 Switch Settings 19
2 Getting Started 21
Installation 21
RIM-1000 Wiring 21
Power Supply and Ground Connections 21
Universal Input Connections 23
Relay 1 and 2 Connections 25
Keypad Connection 26
EIA-232 COM2 Connection 26
RJ11 Phone Line Connection 27
RJ45 Ethernet Connection 27
Modbus EIA-485 Connections 28
Modbus EIA-232 Connections 29
Expansion Card A Connections 30
Expansion Card C Connections 32
Communication 33
Set the RIM-1000 IP Address 33
Set the IP Address Using the ARP and PING Commands 33
Obtain the Ethernet Address (MAC Address) 33
Use the ARP Command 33
Use the PING Command 34
Troubleshooting the ARP/PING Commands 34
Set the IP Address Using a Web Browser 34
Set the RIM-1000 IP Address using an EIA-232 Connection 35
3 Web Interface Configuration 37
Home Page 37
Alarms 39
Identity 40
Configuration 41
Inputs and Relays 41
Main Card - Input Channels 1-8 44
Expansion Card “A” Input Configuration 52
Expansion Card “C” Input Configuration 53
Internal Temperature and Internal Humidity Configuration 53
Relay Configuration 54
System 58
Alarm Management 61
Trends 63
Clock 64
Schedules 65
Battery Supply/Voltage 66
URL Links (1-5) and URL Links (6-10) 67
Links 68
