4.7. Additional Modbus Information
4.7.1 Slave Register Map
Table 4.8 Slave Register Map
Register Description Range
40001 Input #1 value -32678 – 32767
40104 Input #104 value -32678 – 32767
40105 Internal Temperature Sensor -32678 – 32767
40106 Internal Humidity Sensor -32678 – 32767
40107-40187 Reserved
40188-40193 MAC address 00:90:5b:01:01:01
40194-40197 IP address 10.0.0.203
40198 Model Number 100
40199 Firmware Version 73
40200 Number of Alarms Present 0 – 65535
40201 Input #1 alarm bit map 0 – 0x0010
40304 Input #104 alarm bit map 0 – 0x0010
40305 Internal Temperature Sensor - alarm bit map 0 – 0x0010
40306 Internal Humidity Sensor - alarm map 0 – 0x0010
40307-40400 Reserved
40401 Input #1 config code 0 – 7
40504 Input #104 config code 0 – 7
