A P P E N D I X
F
RIM-1000 SLOT DESIGNATIONS
F.1.
Input Slot Designation Table
Alarm ID format:
• XYYZ - X is the Slot # 0-4
• YY is the CH # 1-24
• Z is the type: 0=digital, 1=HighLevel1, 2=LowLevel1, 3=HighLevel2, 4=LowLevel2
Table F.1 Input Slot Designation Table – Slot 0
Slot 0
Number
Port / CH
CH ID
Analog Alarm ID
Digital Alarm ID
RIM-Cxxx
8
1 - 8
0.1 - 0.8
0011 - 0084
0010 - 0080
RIM-CCxx
8
1 - 8
0.1 - 0.8
0011 - 0084
0010 - 0080
RIM-CCCx
8
1 - 8
0.1 - 0.8
0011 - 0084
0010 - 0080
RIM-CCCC
8
1 - 8
0.1 - 0.8
0011 - 0084
0010 - 0080
RIM-CAxx
8
1 - 8
0.1 - 0.8
0011 - 0084
0010 - 0080
RIM-CAAx
8
1 - 8
0.1 - 0.8
0011 - 0084
0010 - 0080
RIM-CAAA
8
1 - 8
0.1 - 0.8
0011 - 0084
0010 - 0080
RIM-CCAx
8
1 - 8
0.1 - 0.8
0011 - 0084
0010 - 0080
RIM-CCAA
8
1 - 8
0.1 - 0.8
0011 - 0084
0010 - 0080
RIM-CCCA
8
1 - 8
0.1 - 0.8
0011 - 0084
0010 - 0080
RIM-Axxx
8
1 - 8
0.1 - 0.8
0011 - 0084
0010 - 0080
RIM-AAxx
8
1 - 8
0.1 - 0.8
0011 - 0084
0010 - 0080
RIM-AAAx
8
1 - 8
0.1 - 0.8
0011 - 0084
0010 - 0080
RIM-AAAA
8
1 - 8
0.1 - 0.8
0011 - 0084
0010 - 0080
IntTempSensor
5.1
-
-
5011 - 5014
-
IntHumidSensor
5.2
-
-
5021 - 5024
-
LowBatteryAlarm
-
-
-
6010
-
Pager Alarm
-
-
-
6020
-
