Remote Infrastructure Management System - Version 1.0 / July 2014
Chatsworth Products, Inc. (CPI) • 800-834-4969 213
Table I.1 Technical Specifications (continued)
Alarm Notification
Pager (Modem)
15 Text, numeric, or alphanumeric pager numbers; each
digital and analog alarm (HighLimit and LowLimit)
can notify any 5 of the 15 pagers
Email
(Ethernet, Modem PPP) 8 Email recipients; email sent on Alarm and Return To Normal; each Alarm can
notify any or all of the 8 email recipients
SNMP Traps (Ethernet) V1, V2c: 8 Community Strings; V3 (optional): 4 users, 4 Trap Destinations
Escalation (Modem)
Additional notification to 1 of the 15 pager numbers when
the initial page results in a Failure To Acknowledge status
Health Check/Self
Monitoring
Self resetting; captured in Event Log
Internal Hardware
Real Time Clock Battery backed; ±1.53 min/month accuracy
Memory 16 MB RAM; 128K NVRAM; 16MB Flash
Logging Capabilities
Alarm Log Last 256 Alarms
Event Log
Last 100 Events (e.g., Acknowledgement By Code, System
Boot, Page Successful, etc.)
Web User Access Log Last 100 HTML Accesses (User, Date, and Time)
Digital Status Log Last 100 Digital Status entries
Trending of Analog Inputs
244 Entries per time frame, per channel
Minute - Every minute, high/low/avg for the last 65 minutes
Hour - Every hour, high/low/avg for the last 25 hours
Day - Every day, high/low/avg for the last 7 days
Extended Trending of Analog
Inputs
3,840 entries over 32 inputs either physical or Modbus;
logging every 1 minute, 5 minute, 15 minute, 1 hour, 2 hour,
4 hour, 6 hour and 8 hour intervals.
Login Security
Web Browser Access
(Ethernet, Modem PPP) 1 Administrator plus 7 Users individually selectable for Read
Only, Read/Write or Administrator
Terminal Emulation Access
(Modem)
1 Administrator (password for Modem access)
Front Panel Interface
Switches Power: 1 (on/off)
LED Indicators
Power: 1 green (on/off); Status: 1 red (flashing = boot up, on = alarm,
off = normal); Network Link: 1 bi-color (green = active, red = not active);
Network Activity: 1 green; Modem: 3 green (transmit, receive, and off hook),
1 amber (carrier detect)
