3.4.17 ICMP Ping
ICMP Ping: Allows a user to ping an IP address from the RIM-1000. The results of the ping will display below in the “Last Ping Results”
table.
Figure 3.32 ICMP Ping Page
Table 3.21 ICMP Ping Options
Option Description
IP Address to Ping
Enter the IP address of the device you’d like to ping. Click the
Submit Changes button to ping the device, at which time the results
will load into the fields below the address.
