Remote Infrastructure Management System - Version 1.0 / July 2014
102 www.chatsworth.com
Table 3.27 Modbus/SNMP/BACnet Slave Configuration Options
Option Description
Return Click this link to return to the previous page.
Download xml for
this device
Click this link to download xml from this specific Slave device.
Upload xml for this
device
Click this link to upload xml to this specific Slave device.
Preset Registers
If you’re configuring a Veris 8036, a Veris E30C, a Veris E50C, or a CPI RIM-750,
we’ve done some of the work for you. Click the Preset Registers button, select
the appropriate device type, and enter the start index number. Click the Submit
Changes button when you’re done to populate the data.
Figure 3.41 Preset Registers Menu
Remove Device
Registers
This button provides a quick way to delete one or multiple Modbus slave
registers. If you click this button for a particular device, all related registers
associated with this device will be deleted.
