F.2.
Output Slot Designation Table
Table F.6 Output (Relays) Slot Designation Table – Slots 0 and 1
Table F.6 Output (Relays) Slot Designation Table – Slots 2 and 3
Number
Relay
Relay ID
Number
Relay
Relay ID
Number
RIM-Cxxx
2
1 - 2
0.1 - 0.2
0
-
-
RIM-CCxx
2
1 - 2
0.1 - 0.2
0
-
-
RIM-CCCx
2
1 - 2
0.1 - 0.2
0
-
-
RIM-CCCC
2
1 - 2
0.1 - 0.2
0
-
-
RIM-CAxx
2
1 - 2
0.1 - 0.2
0
-
-
RIM-CAAx
2
1 - 2
0.1 - 0.2
0
-
-
RIM-CAAA
2
1 - 2
0.1 - 0.2
0
-
-
RIM-CCAx
2
1 - 2
0.1 - 0.2
0
-
-
RIM-CCAA
2
1 - 2
0.1 - 0.2
0
-
-
RIM-CCCA
2
1 - 2
0.1 - 0.2
0
-
-
RIM-Axxx
2
1 - 2
0.1 - 0.2
8
2 - 10
1.1 - 1.8
RIM-AAxx
2
1 - 2
0.1 - 0.2
8
2 - 10
1.1 - 1.8
RIM-AAAx
2
1 - 2
0.1 - 0.2
8
2 - 10
1.1 - 1.8
RIM-AAAA
2
1 - 2
0.1 - 0.2
8
2 - 10
1.1 - 1.8
Number
Relay
Relay ID
Number
Relay
Relay ID
Number
RIM-Cxxx
0
-
-
0
-
-
RIM-CCxx
0
-
-
0
-
-
RIM-CCCx
0
-
-
0
-
-
RIM-CCCC
0
-
-
0
-
-
RIM-CAxx
8
11 - 18
2.1 - 2.8
0
-
-
RIM-CAAx
8
11 - 18
2.1 - 2.8
8
19 - 26
3.1 - 3.8
RIM-CAAA
8
11 - 18
2.1 - 2.8
8
19 - 26
3.1 - 3.8
RIM-CCAx
0
-
-
8
19 - 26
3.1 - 3.8
RIM-CCAA
0
-
-
8
19 - 26
3.1 - 3.8
RIM-CCCA
0
-
-
0
-
-
RIM-Axxx
0
-
-
0
-
-
RIM-AAxx
8
11 - 18
2.1 - 2.8
0
-
-
RIM-AAAx
8
11 - 18
2.1 - 2.8
8
19 - 26
3.1 - 3.8
RIM-AAAA
8
11 - 18
2.1 - 2.8
8
19 - 26
3.1 - 3.8
