3.4.12.1 Configure Phone Numbers
Up to 15 unique phone numbers can be configured to receive RIM-1000 alarm notifications. Use the numerical links at the bottom of
the phone number configuration screen to set these pager and cell phone numbers.
Figure 3.26 Phone Number Configuration
Table 3.15 Phone Number Configuration Options
Option Description
Select Phone Type
Determines which type of device the RIM-1000 calls.
• Choose the Alpha-numeric Pager/Cell Phone option to dial an alphanumeric
pager or cell phone. (Requires optional P/N 60104-001)
• Choose SMS/TEXT/GSM if using an external GSM modem that is connected
to the RIM-1000 COM1 EIA-232 port.
• Choose SNPP for paging over Ethernet - this is a feature some cell/pager
providers do not support.
TAP Number/SNPP
Server
Enter the pager service number for alphanumeric pager or cell phone entries. If
using the SMS/TEXT/GSM, enter the cell phone number to dial. For a list of SNPP
Addresses, go to www.notepage.net/snpp.htm.
Each comma after the number represents a two second delay. This delay allows
time for the service to answer before requesting the pager ID. Typically, it will
only be necessary to use one comma between pager numbers. However, based
on set-up and pager services, users may need to experiment with the number of
commas that are used. In some cases, a 9 must be entered to access an outside
line.
