4.6.1.1 CB# Links
Pressing a CB # (CH#) link displays the Circuit Breaker Configurations for each BCM.
Figure 4.14 Circuit Breaker Configurations for Individual BCMs
Table 4.7 Circuit Breaker Configurations for Individual BCMs
Option Description
Label
Enter a label to describe the circuit breaker. The label is included in
notifications and for identification on the Slave Unit Monitoring page.
Zero Amp Enable
Check to enable alarm and notification if the branch circuit current
falls below the zero amp level as set on the Slave Configuration page.
Breaker Size Enter the circuit breaker size in the BCM.
Warning Threshold Enter the warning threshold level-in percent-in the BCM.
Alarm Threshold Enter the alarm threshold level-in percent-in the BCM.
Warning Time Delay Enter the warning time delay-in seconds-in the BCM.
Alarm Time Delay Enter the alarm time delay-in seconds-in the BCM.
