3.4.7 Schedules
The Schedules page allows users to schedule the activation and deactivation of relay outputs. This is useful for cycling redundant
equipment such as chillers, generators, etc. Relays are assigned these schedules through the Relay Configuration menus.
Figure 3.17 Schedules Configuration Page
Table 3.9 Schedules Configuration Options
Option Description
Status
A non-editable field, this will show the schedule as active or inactive depending
on the criteria you enter in the date and time fields.
Begin DOW The day of the week the schedule will begin.
End DOW The day of the week the schedule will end.
Begin Time The time the schedule will begin.
End Time The time the schedule will end.
