Chatsworth Products Remote Infrastructure Management (RIM-1000) - Manual (Page 214)

Remote Infrastructure Management System - Version 1.0 / July 2014
214 www.chatsworth.com
Table I.1 Technical Specifications (continued)
Operating Environment
Temperature 32° to 158°F (0° to 70°C)
Humidity 5% to 95% RH, non-condensing
Altitude 15,000ft (4,572m) max.
Storage Environment -40º to 185ºF (-40º to 85ºC)
Dimensions
1U RIM-1000: 16.8"W x 1.8"H x 7.9"D (427 mm W x 46 mm H x 201 mm D)
2U RIM-1000: 16.8"W x 3.5"H x 7.9"D (427 mm W x 89 mm H x 201 mm D)
Weight
1U 6 lbs. (2.72kg)
2U 10 lbs. (4.54kg)
Mounting
1U
Rack mount, or wall mount (brackets required): CPI P/N 60105-001 wall
mount brackets (not included)
2U
Rack mount, or wall mount (brackets required): CPI Wall mount brackets
(not included)
Certifications
CE; ETL listed: conforms to UL STD 61010A-1, EN STD
61010; certified to CAN/CSA C22.2 STD NO. 1010.1; RoHS
compliant
