Chatsworth Products Remote Infrastructure Management (RIM-1000) - Manual (Page 147)

Remote Infrastructure Management System - Version 1.0 / July 2014
Chatsworth Products, Inc. (CPI) • 800-834-4969 147
4.7.2 Alarm Bit Map (Reg 40201–-40306)
Table 4.9 Alarm Bit Map
4.7.3 Configuration Codes (Reg 40401–40504)
Table 4.9 Alarm Bit Map
Bit Map Description
0x0000 No Alarm
B:0 0x0001 High1 Alarm
B:1 0x0002 Low1 Alarm
B:2 0x0004 High2 Alarm
B:3 0x0008 Low2 Alarm
B:4 0x0010 Digital Alarm
Code Description
0 Not Installed
1 Not Configured
2 Analog 4-20ma
3 Digital NO
4 Digital NC
5 Digital Status
6 Analog 0-5V
7 Analog 0-10V
