Remote Infrastructure Management System - Version 1.0 / July 2014
Chatsworth Products, Inc. (CPI) • 800-834-4969 189
A P P E N D I X
E
ALARM ID REFERENCE TABLES
E.1. Analog Tables
Table E.1 Analog Alarm ID Reference Table – Inputs 1 through 8
Analog Inputs 1 through 8
Channel Condition ID Channel Condition ID
1 High Limit 1 0011 5 High Limit 1 0051
1 Low Limit 1 0012 5 Low Limit 1 0052
1 High Limit 2 0013 5 High Limit 2 0053
1 Low Limit 2 0014 5 Low Limit 2 0054
2 High Limit 1 0021 6 High Limit 1 0061
2 Low Limit 1 0022 6 Low Limit 1 0062
2 High Limit 2 0023 6 High Limit 2 0063
2 Low Limit 2 0024 6 Low Limit 2 0064
3 High Limit 1 0031 7 High Limit 1 0071
3 Low Limit 1 0032 7 Low Limit 1 0072
3 High Limit 2 0033 7 High Limit 2 0073
3 Low Limit 2 0034 7 Low Limit 2 0074
4 High Limit 1 0041 8 High Limit 1 0081
4 Low Limit 1 0042 8 Low Limit 1 0082
4 High Limit 2 0043 8 High Limit 2 0083
4 Low Limit 2 0044 8 Low Limit 2 0083
