PROFIBUS DP
30. START-UP PROFIBUS DP
30.1. Safety instructions
WARNING!
Risk.of.injury.from.improper.operation!
Improper operation may result in injuries as well as damage to the device and the area around it
• Before start-up, ensure that the operating personnel are familiar with and completely understand the contents
of the operating instructions.
• Observe the safety instructions and intended use.
• Only adequately trained personnel may start up the equipment/the device.
Before start-up, carry out fluid installation (see Chapter “13”) and electrical installation (Chapter “29”) of
Type 8792/8793 and of the valve.
30.2. Start-up sequence
For start-up of Type 8792/8793 PROFIBUS DP the following basic settings are required:
Device.type Sequence Type.of.basic.setting Setting.via Description.
in.chapter
8792 and 8793 1 Adjust device to the local conditions X.TUNE “23.2”
For.8793.only
(Process
control)
2 Activate process controller. ADD.FUNCTION “24”
8792 and 8793
Settings on Type 8792/8793:
BUS.COMM “30.3”
3 Input device address.
4 Activate or deactivate safety position.
Configuration via the control
(PROFIBUS DP Master):
PROFIBUS DP
Master by means
of GSD file and
special software
“30.4” 5 Configuration of the process values
1.
PDI: Process data input
2. PDO: Process data output.
Table 105: Start-up sequence for PROFIBUS DP
