128
Auxiliary functions
26.2.14.2. OUT BIN1 / OUT BIN2 - Configuring the binary outputs
The following description is valid for both binary outputs OUT BIN 1 and OUT BIN 2, as the operation in the menu
is identical.
The binary outputs 1 and 2 can be used for one of the following outputs:
POS.Dev
Exceeding the permitted control deviation
POS.Lim-1/2 Current position with respect to a specified limit position (> or <)
Safepos
Actuator in safety position
ERR.SP/CMD Sensor break (SP = process set-point value / CMD = set-point value position)
ERR.PV
Sensor break (process actual value). Available.for.Type.8793.only.
Remote
Operating state (AUTOMATIC / MANUAL)
Tune.Status Status X.TUNE (process optimization)
DIAG.State-1/2 Diagnosis output (option)
Overview.of.possible.outputs.and.associated.switching.signals:
Menu.option Switching.signal Description
POS.Dev
0 Control deviation is within the set limit.
1 Control deviation is outside the set limit.
POS.Lim-1/2
0 Actual position is above the limit position.
1 Actual position is below the limit position.
Safepos
0 Actuator is not in the safety position.
1 Actuator is in the safety position.
ERR.SP/CMD 0 No sensor break available.
ERR.PV 1 Sensor break available.
Remote
0 Appliance is the AUTOMATIC operating state.
1 Appliance is the MANUAL operating state.
Tune.Status
0 The X.TUNE function is currently not running.
1 The X.TUNE function is currently running.
0/1 alternating
(10 s)
The X.TUNE function was stopped during execution by a fault.
DIAG.State-1/2
0 No diagnosis message available for the selected status signals.
1 Diagnosis message available for the selected status signals.
Table 56: OUT BIN 1/2; Possible outputs and associated switching signals
Switching.signal
Switching.statuses
normally.open normally.closed
0 0 V 24 V
1 24 V 0 V
Table 57: OUT BIN 1/2; switching statuses
