The cameras also have an advanced register which allows even more precise
delay of image capture after receiving a hardware trigger.
Trigger delay advanced register
The advanced register allows the start of the integration to be delayed by
max. 2
21
µs, which is max. 2.1 s after a trigger edge was detected.
Register Name Field Bit Description
0xF0F00834 TRIGGER_DELAY Presence_Inq [0] Presence of this feature:
0: Not available
1: Available
Abs_Control [1] Absolute value control
O: Control with value in the
value field
1: Control with value in the
absolute value CSR. If this
bit= 1 the value in the
value field has to be
ignored.
--- [2..5] Reserved
ON_OFF [6] Write ON or OFF this feature
ON=1 Read: Status of the
feature
OFF=0
---- [7..19] Reserved
Value [20..31] Value
Table 25: Trigger Delay CSR
Register Name Field Bit Description
0xF1000400 TRIGGER_DELAY Presence_Inq [0] Indicates presence of this
feature (read only)
--- [1..5] -
ON_OFF [6] Trigger delay on/off
--- [7..10] -
DelayTime [11..31] Delay time in µs
Table 26: Trigger Delay Advanced CSR
