How does bandwidth affect the frame rate?
GUPPY Technical Manual V7.1.0
223
Test image 2 (Mono8 mode) progressive
Test image 1 and 2 (Mono8 mode) interlaced
Figure 118: Test image 2 progressive
Figure 119: Test image 1 (static) interlaced (Format_7 Mode_1)
Note

• Test image 2 interlaced is the same as test image 2 but
moving.
• Test images show correct colors only in Format_7
Mode_1.
without Debayering with Debayering
without Debayering with Debayering
