Configuration of the camera
GUPPY Technical Manual V7.1.0
243
410h
..
47Fh
Reserved Address error on access
480h Advanced_Feature_Inq Advanced_Feature_Quadlet_Offset [0..31] Quadlet offset of the advanced
feature CSR's from the base
address of initial register
space (Vendor unique)
This register is the offset for
the Access_Control_Register
and thus the base address for
Advanced Features.
Access_Control_Register does
not prevent access to
advanced features. In some
programs it should still always
be activated first. Advanced
Feature Set Unique Value is
7ACh and CompanyID is
A47h.
484h PIO_Control_CSR_Inq PIO_Control_Quadlet_Offset [0..31] Quadlet offset of the
PIO_Control CSR's from the
base address of initial register
space (Vendor unique)
488h SIO_Control_CSR_Inq SIO_Control_Quadlet_Offset [0..31] Quadlet offset of the
SIO_Control CSR's from the
base address of initial register
space (Vendor unique)
48Ch Strobe_Output_CSR_Inq Strobe_Output_Quadlet_Offset [0..31] Quadlet offset of the
Strobe_Output signal CSR's
from the base address of ini-
tial register space (Vendor
unique)
Offset Name Field Bit Description
Table 103: Feature presence inquiry register
