Configuration of the camera
GUPPY Technical Manual V7.1.0
240
25Ch
V_RATE_INQ
(Format_2, Mode_7)
FrameRate_0
[0]
1.875 fps
FrameRate _1
[1]
3.75 fps
FrameRate _2
[2]
7.5 fps
FrameRate _3
[3]
15 fps
FrameRate _4
[4]
30 fps
FrameRate _5
[5]
60 fps
FrameRate _6
[6]
Reserved
FrameRate _7
[7]
Reserved
-
[8..31]
Reserved
260h
…
2BFh
Reserved V_RATE_INQ_y_x (for other Format_y, Mode_x)
2C0h
V_REV_INQ_6_0 (Format_6, Mode0)
Always 0
2C4h
..
2DFh
Reserved V_REV_INQ_6_x (for other Mode_x of Format_6) Always 0
2E0h
V-CSR_INQ_7_0
[0..31]
CSR_quadlet offset for Format_7
Mode_0
2E4h
V-CSR_INQ_7_1
[0..31]
CSR_quadlet offset for Format_7
Mode_1
2E8h
V-CSR_INQ_7_2
[0..31]
CSR_quadlet offset for Format_7
Mode_2
2ECh
V-CSR_INQ_7_3
[0..31]
CSR_quadlet offset for Format_7
Mode_3
2F0h
V-CSR_INQ_7_4
[0..31]
CSR_quadlet offset for Format_7
Mode_4
2F4h
V-CSR_INQ_7_5
[0..31]
CSR_quadlet offset for Format_7
Mode_5
2F8h
V-CSR_INQ_7_6
[0..31]
CSR_quadlet offset for Format_7
Mode_6
2FCh
V-CSR_INQ_7_7
[0..31]
CSR_quadlet offset for Format_7
Mode_7
Offset
Name
Field
Bit
Description
Table 101: Frame rate inquiry register
