Configuration of the camera
GUPPY Technical Manual V7.1.0
250
80Ch WHITE-BALANCE Presence_Inq [0] Presence of this feature
0: N/A
1: Available
Always 0 for Mono
Abs_Control [1] Absolute value control
0: Control with value in the Value
field
1: Control with value in the Absolute
value CSR
If this bit = 1, value in the Value field
is ignored.
[2-4] Reserved
One_Push [5] Write '1': begin to work (Self cleared
after operation)
Read: Value='1' in operation
Value='0' not in operation
If A_M_Mode =1, this bit is ignored.
ON_OFF [6] Write: ON or OFF this feature,
Read: read a status
0: OFF
1: ON
If this bit =0, other fields will be read
only.
A_M_Mode [7] Write: set the mode
Read: read a current mode
0: Manual
1: Auto
U_Value /
B_Value
[8-19] U Value / B_Value
Write the value in AUTO mode, this
field is ignored.
If ReadOut capability is not avail-
able, read value has no meaning.
V_Value /
R_Value
[20-31] V value / R value
Write the value in AUTO mode, this
field is ignored.
If ReadOut capability is not avail-
able, read value has no meaning.
Offset Name Field Bit Description
Table 106: Feature control register
