Introduction
GUPPY Technical Manual V7.1.0
10
Introduction
This GUPPY Technical Manual describes in depth the technical specifica-
tions, dimensions, all camera features (IIDC standard and AVT smart fea-
tures) and their registers, trigger features, all video and color formats, band-
width and frame rate calculation.
For information on hardware installation, safety warnings, pin assignments
on I/O connectors and 1394b connectors read the Hardware Installation
Guide.
Document history
Note

Please read through this manual carefully.
We assume that you have read already the Hardware
Installation Guide and that you have installed the hard-
ware and software on your PC or laptop (FireWire card,
cables).
Version Date Remarks
V2.0.0 06.04.2006 New Manual - RELEASE status
V2.0.1 28.06.2006 RoHS conformity; minor corrections
PRE_V3.0.0 30.10.2006 Minor corrections
Input characteristics: Added description to input voltage
Added Guppy F-036B/C
Correction in Chapter Multi-shot on page 186
New CAD drawing in Figure 23: Camera dimensions (new CS-/
C-Mounting) on page 65.
New CAD drawing in Figure 29: Guppy C-Mount dimensions on
page 71.
New CAD drawing in Figure 30: Guppy CS-Mount dimensions
on page 72.
to be continued on next page
Table 1: Document history
