Specifications
GUPPY Technical Manual V7.1.0
30
Digital interface IEEE 1394a IIDC V1.3, single port
Power requirements DC 8 V - 36 V via IEEE 1394 cable or 8-pin HIROSE
Power consumption Less than 2 watt (@ 12 V DC)
Dimensions 48.2 mm x 30 mm x 30 mm (L x W x H); w/o tripod and lens
Mass 50 g (without lens)
Operating temperature + 5 °C ... + 45 °C housing temperature (without condensation)
Storage temperature - 10 °C ... + 60 °C ambient temperature (without condensation)
Regulations FCC Class B, CE, RoHS (2002/95/EC)
Standard accessories • b/w: C/CS-Mount with built-in protection glass
• color: C/CS-Mount with built-in IR cut filter
Optional accessories • Board level OEM version
• b/w: C/CS-Mount: IR cut filter / IR pass filter available as CS-
Mount adapter.
• color: C/CS-Mount: protection glass available as CS-Mount
adapter.
Software packages • AVT FirePackage (SDK and Viewer, 100% control the bus)
• AVT Direct FirePackage (SDK and Viewer, compatible to DirectX
and WDM)
• AVT Fire4Linux (SDK and Viewer, compatible to RedHat and
Suse Distributions)
Note

The design and specifications for the products described
above may change without notice.
Feature Specification
Table 7: Specification Guppy F-033B/C
