Description of the data path
GUPPY Technical Manual V7.1.0
103
Figure 52: Format_7 Mode_0: output (interlaced, field)
Parameter Description
Output during first field Line 1+2, 3+4, ... are output as line 1, 3, ...
Output during second field Line 2+3, 4+5, ... are output as line 2, 4, ...
Sensitivity Doubled by field integration
Vertical resolution About 70% (due to interlaced) compared to progressive scan
Temporal resolution High (reason: one field contains the full sensor information).
Electronic shutter Possible
Color reproduction Possible, has to be done digitally in viewer (e.g. SmartView or by
separate UniTransform.dll)
Table 36: Format_7 Mode_0: output parameters (interlaced, field)
