Description of the data path
GUPPY Technical Manual V7.1.0
100
Color cameras (CCD and CMOS)
Figure 48: Block diagram color camera (CCD)
Figure 49: Block diagram color camera (CMOS)
Camera Control
CCD: Analog Front End (AFE)
Test-Pa
ttern
IEEE-1394
Interface
1
394a
Camera I/O Connector
RS232
Sensor
Analog
Gain
Analog
Offset
10* bit
White Balance
10* bit
LUT
8*
* Bit
Camera control
CMOS: Integrated in sensor
T
e
s
t-P
at
te
rn
IEEE 1394
interface
1394a
Camera I/
O connector
RS
232
Sensor
Analog
Offset
Analog
Gain
10* bit
White balance
10* bit
LUT
8** bit
